Showing all 9 results

Read more

LF01 series fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 6A|15A|25A|50A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF01 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high-temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF01-06 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 6A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF01 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high-temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF01-15 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 15A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF01 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high-temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF01-25 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 25A
Output: 2.5±4V@IPN
Supply Voltage: 5V

The LF01 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high-temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF01-50 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 50A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF01 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high-temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF03 series fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 50A|100A|150A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF03 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF03-100 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 100A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF03 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF03-150 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 150A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF03 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.

Read more

LF03-50 fluxgate current sensor

Accuracy: 0.1%
Measuring Range: 50A
Output: 2.5±0.625V@IPN
Supply Voltage: 5V

The LF03 series fluxgate current sensor incorporates dynamic fluxgate detection technology. Its design is simple and practical, with the ability to inhibit high temperature drift. Fluxgate technology makes use of the phenomenon of magnetic core saturation to modulate the measured magnetic field, transforming it into an electric field and thus, completing the magnetic field measurement process.
